Regular Expressions Demystified

Overview

• Regular expressions are one of the most fundamental tools used in Natural Language processing.
• Used to search for strings using a pattern.
• Platform independent: same regex used in your favorite programming language can be used in a text editor like VSCode.
• With regular expressions you can return a single match or an entire list of them that match the pattern.
• There are many variants of regular expressions. This article will dwell into extended regular expressions.
• Regular expressions are case sensitive. (Therefore, One != one)
• Regular expressions are greedy by default.

Follow along

• An interactive python notebook with code referencing this examples can be found at: Google Colab

Sequences

• An ordered combination of one or more characters.

Ex:

For the sentence: once upon a time in oncelot, there was once a roncean

Disjunction

• Disjunction allows us to search for strings with variations.
• The number of possible variations that are allowed for a string are enclosed in square brackets. ([])
• For example, if we have a string: "Natural habitats with natural biology are affected by natural disasters".
• There are a few characters that when used within a square bracket give a special meaning: "^", "-".
• -: is used to define a range.
• For example, if we want to search for all numbers we can use: [0123456789].
• However, this is quite bothersome and tiring, this is where we can use: [0-9] to signify a range of 0 to 9.
• ^: Used to denote negation.
• ^ has to be the first character within square brackets for it to count as negation.
• If ^ appears at a different position within square brackets such as the middle it denotes a normal "^" sign.

Ex:

For the text: Natural habitats with natural biology are affected by natural disasters

For the text: abcAZ907

For the text: abcAZ907

Counters

• Counters allow us to define patterns with a variable number of a characters.
• ?: Zero or one instance.
• *: Zero or more instances
• +: One or more instances
• {number}: Specific number of instances

Ex:

For the text: The word color is sometimes referred to as colour in some interpretations.

For the expression: ba*!

For the expression: ba+!

For the text: baaaaa!

Anchors

• Regular expressions used to denote a particular place for a string.
• ^: Used to denote the start of a line.
• $: Used to denote the end of a line.
• \b: Used to denote a word boundary.
• \B: Used to denote a non word boundary.
• A word in regex: sequence of letters, digits and underscores(_).
• Thus, special characters like "$" or "!" will not count as a word boundary

Ex:

For python specifically, you need to enable the multiline flag to identify new lines:

flags = re.MULTILINE if multiline else 0
compiled_pattern = re.compile(pattern, flags)
matches = compiled_pattern.finditer(text)

For the text: There was the person that was running t^he shop and they came and went.\nThe shop opened next day t\nhe

For the text: The man wrote a thesis on rafther and there were others who read it and the people who read it were satisfied. The_ $99! price was on$the tag with an id code of _99_ 99a.

Wildcard character

• . : Used to denote the possibility of any character

Ex:

For the expression te.m

For the expression te.*m

Order precedence

• The most important part of understanding a regex is understanding precedence.
• Lets say we have the regex one|two which means search for a string with a sequence of one or two but for onewo or ontwo.
• Consider boe* which means search for a string with the sequence bo with zero or more occurrences of e but not for boeboe or boeboeboe.
• This is due to order precedence.
• Certain operators have a higher order of precedence and evaluated first similar to algebra.
• Similar to evaluating an algebraic expression, regex also needs to be evaluated in order.
• Parenthesis allows us to increase the order of precedence

Order of precedence is as follow:

• Since Disjunction has lower precedence than Sequences: one|two the two sequences one and two are first evaluated then the disjunction.
• Since counters have higher priority than sequences: boe* the sequence is evaluated after and counter is applied to the character to its left.
• However with parenthesis we can manipulate the order to our liking
• If we want to search for onewo or ontwo instead of one or two we can use the regex: on(e|t)wo
• If we want to search for poepoepoe where the string poe is repeated 0 or more times: (poe)*

Ex:

For the expression poe*

For the expression: (poe)*

For the expression: one|two

For the expression: on(e|t)wo

Other special characters:

• These characters are mainly used as shorthand for common patterns:

Greedy expressions

• Regular expressions are greedy by default.
• Lets say we have a input string of "His name was poeee" to which we apply the regular expression *"poe"**.
• The regular expression searches for a string with a sequence of 'po' followed by 0 or more e's.
• Now given our input string it can return po, poe, poee or poeee.
• However, from these options the string that will be returned as an output would be poeee.
• This is because regex are greedy and will try to match the expression to the longest possible string.
• However, we can also enforce a non-greedy approach by using the ? symbol along with the * or + symbols.

Ex:

For the text: His name was poeee

Substitutions and Capture Groups

• In addition to changing the default order of precedence, parenthesis(()) can also be used to capture and store patterns.
• If a pattern within a parenthesis matches an expression that pattern gets stored in a memory register.
• For example lets say we have an input string of: He was big but his opponent was bigger.
• We then apply a regular expression to it of: He was (.)* but his opponent was \1ger.
• This expression will create a valid match as the parenthesis matches the string big and stores it within a memory register references by \1.

Ex:

For the expression: He was (.*) but his opponent was \1er

• Regular expressions are evaluated from left to right and therefore the strings matched by the expressions get stored in memory registers in order.
• It is possible to store multiple expressions and reference them using the sequential order they are stored in.
• \1 will store the fist expression captured within parenthesis while \2 will match the second and so on.
• A common use case for these capture groups is for substitutions.

Ex:

For the input string: 42 apples, 17 bananas, 3 oranges

Lets say we want to get the total number of fruits

import re
# Define a regular expression pattern with capture groups
pattern = r'(\d+) (\w+)'
# Input string
text = '42 apples, 17 bananas, 3 oranges'
# Create an empty list to store fruits
fruits_list = []
count = 0
# Define a substitution function that uses captured groups
def repl(match):
    global count
    number = int(match.group(1))
    fruit = match.group(2)
    count += number  # Increment the 'count' variable
    fruits_list.append(fruit)  # Add 'fruit' to the 'fruits_list'
    # Manipulate the captured data or construct a new string
    return f'There are {number} {fruit} in the basket.'
# Perform substitutions using re.sub()
result = re.sub(pattern, repl, text)
print('There are {0} fruits in the basket of {1}'.format(count, ','.join(fruits_list)))
print(result)

This will print:

There are 62 fruits in the basket of apples,bananas,oranges
There are 42 apples in the basket., There are 17 bananas in the basket., There are 3 oranges in the basket.

• Parenthesis by default stores the matched expression in a memory register.
• However, there may be times we want to avoid such a behavior and use it just as a means of altering the order of precedence of an expression.
• This is where we can use the ? symbol to denote that we want to avoid such a behavior.
• For example if we have the regex: (? some|a few) (people|cats) like some \1.
• The expression that will be stored in memory would be people|cats and not some|few.

Ex:

For the expression: (?:some|few) (people|cats) like some \1

Lookahead assertions

• By default expressions are evaluated from left to right.
• Lookahead assertions allow us to scan the text ahead without advancing the match pointer.
• Lookahead assertions are denoted as either ?= or ?! within ().
• ?= is used to check for whether the expression matches and ?! is used to check if the expression does not match.

Ex:

For the text: I love apple pie, but not apple juice or apple tart. apple pie is the best.

Practical examples

• Based on the concepts above lets' use Regex for one of the most common uses in a web application.
• For testing password strength.
• Lets first define the criteria needed for a modern password:
• At,least 8 characters.
• Must contain an uppercase character, a lowercase character, a number and a symbol
• Lets start by defining our first requirement:
• .{8,}
• The wildcard proceeded by a counter of a minimum of 8 ensures that our password

def test_password(password, pattern):
    compiled_pattern = re.compile(pattern)
    if compiled_pattern.match(password):
        print('Password "{0}" passes for expression: {1}\n'.format(password, pattern))
    else:
        print('Password "{0}" fails for expression: {1}\n'.format(password, pattern))

# Allow any characters (wildcard)
starting_regex = r'.*'
password1 = ''
password2 = 'abc'
password3 = 'abcdefgh'
test_password(password1, starting_regex)
test_password(password2, starting_regex)
test_password(password3, starting_regex)

# Minimum 8 characters requirement
min_char_regex = r'^.\{8,\}$'
password4 = 'abcdefghasdaaaaaaaaaaaa'
test_password(password1, min_char_regex)
test_password(password2, min_char_regex)
test_password(password3, min_char_regex)
test_password(password4, min_char_regex)

# We still dont have upper case requirement
# Our password needs to contain atleast one upper case character
# Lets use a lookahead expression to check whether there is a upper case letter
upper_case_regex = r'^(?=.*?[A-Z]).\{8,\}$'
password5 = 'aAa'
password6 = 'AVCDEFGHI'
password7 = 'asdaAdasd123'
test_password(password1, upper_case_regex)
test_password(password2, upper_case_regex)
test_password(password3, upper_case_regex)
test_password(password4, upper_case_regex)
test_password(password5, upper_case_regex)
test_password(password6, upper_case_regex)
test_password(password7, upper_case_regex)

# We still have some more requirements;
# Need a lower case, number and a special character
final_regex = r'^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).\{8,\}$'
password7 = 'asdaAdasd123'
password8 = 'aA2!'
password9 = '#a3aA'
password10 = 'asdaAdasd12!3'
password11 = 'Password123#'
test_password(password1, final_regex)
test_password(password2, final_regex)
test_password(password3, final_regex)
test_password(password4, final_regex)
test_password(password5, final_regex)
test_password(password6, final_regex)
test_password(password7, final_regex)
test_password(password8, final_regex)
test_password(password9, final_regex)
test_password(password10, final_regex)
test_password(password11, final_regex)

This will print:

Password "" passes for expression: .*

Password "abc" passes for expression: .*

Password "abcdefgh" passes for expression: .*

Password "" fails for expression: ^.{8,}$

Password "abc" fails for expression: ^.{8,}$

Password "abcdefgh" passes for expression: ^.{8,}$

Password "abcdefghasdaaaaaaaaaaaa" passes for expression: ^.{8,}$

Password "" fails for expression: ^(?=.*?[A-Z]).{8,}$

Password "abc" fails for expression: ^(?=.*?[A-Z]).{8,}$

Password "abcdefgh" fails for expression: ^(?=.*?[A-Z]).{8,}$

Password "abcdefghasdaaaaaaaaaaaa" fails for expression: ^(?=.*?[A-Z]).{8,}$

Password "aAa" fails for expression: ^(?=.*?[A-Z]).{8,}$

Password "AVCDEFGHI" passes for expression: ^(?=.*?[A-Z]).{8,}$

Password "asdaAdasd123" passes for expression: ^(?=.*?[A-Z]).{8,}$

Password "" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "abc" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "abcdefgh" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "abcdefghasdaaaaaaaaaaaa" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "aAa" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "AVCDEFGHI" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "asdaAdasd123" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "aA2!" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "#a3aA" fails for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "asdaAdasd12!3" passes for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

Password "Password123#" passes for expression: ^(?=.*?[A-Z])(?=.*?[a-z])(?=.*?[0-9])(?=.*?[#?!@$%^&*-]).{8,}$

• Generating a final regular expression consists of fixing two kinds of errors.
• Removing false positives. (Strings we incorrectly matched like abc for the expressions .*) also called precision.
• Including false negatives. (Strings we missed) also called recall.
• We did not have false negatives in the example above but consider we had the expression instead: ^(?=.?[A-Z])(?=.?[a-z])(?=.?[0-9])(?=.?[#?!@$%^&*-]).{9,}$
• We would then miss passwords like "Passwo12#" with 8 characters because we defined a minimum of 9 characters in our expression.
• Such a case would be considered a false negative.
